C-Arm Subsystem
Problem Probable Cause or Remedy
All squares and arrows did not
come on. Error message
appears.
Refer to
Interlocks
chapter of this manual.
Refer to
Bootup
, in the
Diagnostics
chapter of this manual.
Fluoro Mode
If the C-Arm failed the Fluoro Mode Performance Check, use the following fault isolation chart:
Note: The sections listed below are suggested starting points for your troubleshooting. It is likely that you will need to review
other sections also.
Problem Probable Cause or Remedy
No Fluoro image Refer to the kV and mA Generation chapters of this manual.
Image quality unacceptable Refer to Image Intensifier and Power Supply section in the Image Control chapter of this
manual.
Rotation/image reversal
Refer to the CCD Camera chapter of this manual.
Field Size Selection
Refer to the Image Intensifier Tube and Power Supply chapter of this manual.
Collimation failure Refer to the Collimator Control chapter of this manual.
Failure of MODE Control (vascular)
Refer to the Image Intensifier Tube and Power Supply chapter of this manual.
System shuts down without error
messages
Refer to the
Cooling
chapter in this manual.
20
