Diagnostics
Message Type or Code Data Item
OFF – WAIT 5 SECONDS
2-None
CHARGER FAILED Error 1-Battery Voltage (Inverter B A/D)
2-Charge Current (Charger I Sense A/D)
CHARGER FAILED – POWER OFF – WAIT 5
SECONDS
Error 1-Battery Voltage (Inverter B A/D)
2-Charge Current (Charger I Sense A/D)
BATTERY CHARGE - ##% Error 1-Percentage of Capacity
2-Battery Voltage (Inverter B A/D)
COLLIMATOR CAL REQUIRED – PRESS ANY
KEY
Error 0 = Leaves; 1 = Iris; 2 = Leaves and Iris
2-None
COLL IRIS UNSTABLE Error 1-Pot reading
2-None
COLL IRIS POTENTIOMETER ERROR –
PRESS ANY KEY
Error 1-Pot reading
2-None
COLLIMATOR STUCK Error 1-Pot reading
2-None
COLL IRIS TOO LARGE Error 1-Pot reading
2-None
COMMUNICATION FAILED 1-None
2-None
CONTROL PANEL ERROR Error 1-None
2-None
DATA ERROR Error 1-
0 = Program Area
1 = Data Area
17
