Calibration
Camera
decentration
adjusting
screws
Aligning the Camera Rotational Center
k. Tighten the screws of step (i) above.
l. Check the accuracy of the decentration adjustment by repeating above step 1, (a) through (d).
Note: For adjustment of the camera centering relative to the circular mask, refer to Collimator/Camera Calibration section, later
in this chapter.
55
