Calibration
4. Using the photometer, verify that the black and white areas on the left monitor are producing the following illumination levels.
Simulated Minimum Light Settings
Black Panel light level White Panel light level
0.70 to 0.85 Foot Lamberts 145 to 155 Foot Lamberts
Simulated Maximum Light Settings
Black Panel light level White Panel light level
1.10 to 1.25 Foot Lamberts 195 to 205 Foot Lamberts
Light Sensor Calibration Using Rut
Note: For the following procedure, use the RUT utility CD.
1. Verify that the Fostec Light Source is properly adjusted.
2. Place the light source holding bracket over the workstation light sensor.
3. Connect the RUT cable to the laptop and the back of the workstation.
4. Run the RUT program. From the Tools pull down menu select Connect, then Upload and Save to save all data from the 9800
to the laptop.
5. Select the Workstation Calibration form. Click on the Calibrate Light Sensor button at the bottom of the form and follow the
instructions appearing on the laptop.
6. After completing the instructions on the laptop, select the File pull down menu and select the Save Workstation Calibration
File to save the new light sensor calibration data.
7. From the File pull down menu select the Download Workstation Calibration data to the 9800.
8. From the Tools pull down menu select Disconnect.
83
