Side Cover Removal
Note: Rear cover must be removed before side covers or front cover can be removed
Note: Left and right side covers fit into slots in Workstation base and under handles on either side of Workstation.
Remove both side covers by pulling each of them to the rear of the Workstation.
Do not remove
these covers
Side Covers
Side Cover Removal
