OEC 9800C-Arm - Page 434

Replacement
High Voltage
Supply Regulator
PCB
High Voltage Supply Regulator PCB Location
High Voltage Tank
The High Voltage Tank mounts above the batteries and is surrounded by electronic components as shown in the following
illustration.
Use the following procedure to replace the High Voltage Tank:
WARNING: Dangerous voltages are present at many points on the C-Arm.
