Operating Instructions and Parts Manual 24664
4/18
2018 OEMTOOLS
™
ROTARY TOOL
PURPOSE
The OEMTOOLS
™
Rotary Tool with 35 Piece Accessory
Kit polishes, grinds, cuts, shapes, and sands metals
and is great for home hobbyists or garage machinists,
whether professional or novice. All tools needed are
at hand and it accepts all standard accessories and
attachments.
PRODUCT SPECIFICATIONS
Voltage: 120V/60Hz
Input Power: 1.2 Amp
No-Load Speed: 10,000-35,000 RPM
Collet Capacity: 1/8" and 3/32"
Spindle Lock: Yes
Cord Length: 6 Ft.
WARNING: Double insulated tools are equipped
with a polarized plug (one blade is wider than the other).
This plug will fit in a polarized plug only one way. If the
plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician to install
a polarized outlet. DO NOT change the plug in any way.
Double insulation eliminates the need for the three-
wire grounded power cord and grounded power supply
system.
OPERATING INSTRUCTIONS
WARNING: Be sure you read, understand and apply
safety instructions before use.
1. Always inspect, maintain and operate in accordance
with ANSI safety code for power tools and other local
safety codes and regulations.
2. Use clamps or other practical ways to secure and
support the workpiece to a stable platform.
3. DO NOT force the tool. Use the correct tool for the job.
4. Disconnect the plug from the power source before
making any adjustments, changing accessories or
storing the tool.
5. Check for misalignment or binding moving parts,
breakage of parts and any other condition that may
affect the tool’s operation. If damaged, have the tool
serviced before using.
6. Use only accessories that are recommended by the
manufacturer for your model.
7. Hold tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring or its own cord.
8. Always make sure the work surface is free from nails
and other foreign objects.
9. Never hold the workpiece in one hand and the tool in
the other hand when in use. Never place the hands
near or below the cutting surface.
10. Never lay workpiece on hard surfaces like concrete,
stone, etc.
11. After changing the bits and accessories or making
adjustments, make sure the collet nut and any other
adjustment devices are securely tightened.
12. Always wear safety goggles and a dust mask. Use only
in well-ventilated areas. Using personal safety devices
and working in a safe environment reduces risk of
injury.
13. Always use the correct collet size.
14. Always check accessory bits, grinding stones, cut-off
wheels, etc. for damage before each use.
15. Never use dull or damaged bits. Sharp bits must be
handled with care.
16. Never touch the bit during or immediately after use.
17. The Rotary Tool is wired at the factory for 110–120V
operation. It must be connected to a 110–120V, 15A
time delayed fuse or circuit breaker. To avoid shock or
fire, replace power cord immediately if it is worn, cut or
damaged in any way.
18. Avoid accidental starting. Be sure switch is OFF before
plugging in.
19. Remove adjusting keys or wrenches before turning the
tool ON.
NOTE: Most commonly used bits and accessories
with 1/8" and 3/32" shanks will fit this tool. Rotary Tool
accessories, such as a drill press designed for other
Rotary Tools, may not fit this tool.
WARNING: If any part is missing or damaged, do
not plug the Rotary Tool into the power source until the
missing or damaged part is replaced.
WARNING: To avoid fire or toxic reaction, never use
gasoline, naphtha, acetone, lacquer thinner or similar
highly volatile solvents to clean the tool.
