Ofil luminar - Field of View (FOV) Adjustment

15
5. FOV - FIELD OF VIEW
• Affects the working distances & the
resolution of the image. Wider
FOV
is used for shorter distances from the
target object. Narrower FOV provides
higher image resolution
• Move the green frame to the FOV
• Click on the
SELECTOR button to turn on
the FOV function
• A sub menu with 2 options of narrow
and wide views appears
• Move the green frame to the desired
view
• Click on the
SELECTOR to select the view
• The status line will read: W-FOV for
wide FOV and N-FOV for narrow
• NOTE: narrow 5
o
x 3.75
o
wide 10
o
x 7.5
o
field of view
