Safety
Explanation of Symbols
Caution: Risk of Danger - This symbol directs the operator to consult the
instruction manual for safety related warnings. (ISO-7000-0434)
Whenever this symbol is used on the equipment, the user must
consult the manual to determine the nature of the hazard and any
actions which have to be taken.
Fuse: This is the internationally recognized symbol for a user-replaceable
fuse. This symbol will be followed by information required to guide the
user to choose the proper replacement fuse.
Direct Current (DC): This symbol indicates an input (or output) that is
direct current only. (IEC 60417-5013)
Note: This symbol will indicate important notes and helpful hints for the
operation of the equipment.
Polarity: This symbol indicates that the equipment receives positive
voltage on the center pin of the connector and the return voltage is on the
outer case.
Tip: This symbol is used to identify operational information and best
practices to obtain the most reliable data.
Caution: Note - This symbol is used to indicate statements in the manual
which warn against actions which may cause damage to the equipment
during routine service or maintenance
