EN-43Adventurer Pro
5.1 Drawings (Cont.)
A B C
FIGURE MODELS OVERALL HEIGHT OVERALL WIDTH OVERALL DEPTH
5-1 AV64, AV64C, AV114, 30 cm 22 cm 30 cm
AV114C, AV264, AV264C 12 in. 8.7 in. 11.8 in.
AV213, AV213C, AV313, 19 cm 22 cm 30 cm
AV313C, AV413, AV413C 7.5 in. 8.7 in. 11.8 in.
5-2 AV53 14.5 cm 19.3 cm 25.4 cm
5.7 in. 7.6 in. 10 in.
5-3 AV212, AV412, AV812, 7.2 cm 19.3 cm 25.4 cm
AV2101, AV4101, 2.8 in. 7.6 in. 10 in.
AV8101
5-4 AV212C, AV412C, 8.5 cm 22 cm 30 cm
AV812C, AV2101C, 3.3 in. 8.7 in. 11.8 cm
AV2102, AV2102C,
AV3102, AV3102C
AV4101C, AV4102,
