Ranger™ Count 3000 Series EN-5
TABLE 3-1. Cont.
Button
Primary
Function
(Short Press)
0-9
Enter numeric
values on the
display.
Enter decimal
point (.) on the
display.
C
Clear the last
character
from the
display.
Tare
Perform a
tare
operation.
Sample
Display/
Start
new APW
Secondary
Function
(Long Press)
Switch between
scale 1 and
scale 2
(only available
if second
platform is
connected)
+/-
Switch
between
positive and
negative
value
Notes:
1
Short Press: Press less than 1 seconds.
2
Long Press: Press and hold for more than 2 seconds.
TABLE 3-2. LCD Symbols
Item
Description
Item
Description
1
NET symbol
10
Low Sample Weight Symbol
2
Center of Zero symbol
11
Auto Optimization Symbol
3
Negative symbol
12
Dynamic symbol (not used)
4
Stable weight symbol
13
Battery charge symbol
5
Preset Tare, Tare symbols
14
Pound, Ounce, Pound:Ounce symbols
6
Pointer symbols
15
Percent symbol (not used)
7
Accumulation symbol
16
Kilogram, gram symbols
8
Calibration / Menu Mode symbol
17
Pieces symbol, tonne symbol (not used)
9
Low Average Piece Weight Symbol
18
Scale symbol (only shown when 2
nd
platform is connected and turned on)
Notes:
The APW Lo symbol will be lit if the APW value is lower than minimum recommended APW (refer to table 7-1 for
minimum APW).
The Wt Lo symbol will be lit if the sample weight is lower than minimum recommended sample weight (refer to
Table 7-1 for minimum sample weight).
1
7
8
10
11
12
13
14
15
Figure 3-2. LCD Displays
.
2
3
4
5
6
9
16
17
18
Piece Weight
Weight
