SKIPPER 6000
TPLINK WIFI MODULE INSTALLATION AND CONFIGURATION
Ref: 30251574
1
1. INSTALLATION WIFI MODULE IN SKIPPER 6000 SCALES
N.
CODE DESCRIPTION QTY
1 4511013150 WIFI POWER BOARD +24v/+5v “500” TP
LINK
1
2 BCT72A WIFI MODULE + RESET 1
3 BH-P5256 ADAPT. WIFI BLACK 1
4 TO-
CL81Z31006B
SCREW CL81Z 3,1x6 ZINC 2
5 TO-798504005B SCREW DIN7985 M4x5 BICHROMATED 2
6 BK-5906 ETHERNET DATA CABLE 115mm 1
7 BL-P4560 WIFI RESET STICKER 1
