Using the Dispensing Reels
NOTE: Dispensing Reels are optional equipment. If you have ordered Dispensing Reels with
your system,they will be located within the pod directly under the Dispensing Faucets.
See Figure 20.
STEP 1. Place valve handles into Dispense Mode, then press START to start the pump.
STEP 2. Pull on the handle to extend the fluid hose to the desired location or place a container under the nozzle.
STEP 3. Put the nozzle in the required location, ensuring it is secure.
STEP 4. Pull on the red trigger to dispense the fluid.
NOTE: Due to the air that has been trapped in the pipes during assembly, air will come out of
the faucet initially.
Keep the trigger pulled until the fluid starts to flow at a steady pace.
STEP 5. To lock the trigger in open position, squeeze trigger and press the red button on the side of the gun. Squeeze
trigger again to disengage the lock. See Figure 21.
FIGURE 20: Location of Dispensing Reels
