Parts and Pre-Installation Check List
IMPORTANT:
CHECK packaging list to ensure you have all applicable parts before continuing. CONTACT YOUR
SUPPLIER if it appears that any parts are missing or damaged. Refer to the specification sheet for
your customized system for detailed system information including electrical requirements, and total
weight of system.
Each system section is referred to as a “Pod” in this manual. Check that you have received the appropriate number of
Pods for your order. Follow written instructions to assemble and install, prior to operating.
NOTE: For this manual, the Tank Pod/s will each be shown with four 65-gallon Bulk Tanks.
POD 1 – TANK POD POD-2 – TANK POD
Sample 4x65
4 Bulk Tanks 65-gallon size,
color-coded per order specifications, pre-installed)
4 Motor/Pump (pre-installed)
4 Dispensing Faucet (standard style comes with color-
codedball knob, fire upgrade comes as a brass valve)
4 Spin-on Filters
4 Fluid Level Gauge
4 Desiccant Air Breather Air Filter
4 Suction Hose Assembly
4 System Pressure Gauge
4 Isolation Valve (located on underside of tank)
Optional Equipment
4 Fluid Level Gauge Overfill Alarm Spill Pan Connector Kit (see Page 14)
