74 Microline 390/391 Turbo
|
Menu Settings Table (Continued)
For a complete explanation of each menu item, refer to “Using Your Printer, Menu Mode, Explanations of Menu Items.”
The table below shows the items which may appear in the menu. Settings which are engaged at the factory (defaults) are set in
bold italic. Some groups or entries will only appear when a specific emulation is engaged, as noted.
Group Item Settings (Defaults are set in bold italic)
Set-Up Operator Panel Function Full Operation, Limited Operation
(continued) Reset Inhibit No, Yes
Print Suppress Effective Ye s , No
Auto LF No, Yes
Auto CR+ No, Yes
SI Select Pitch (10 cpi) * 17.1 cpi, 15 cpi
SI Select Pitch (12 cpi) * 20 cpi, 12 cpi
Time Out Print Valid, Invalid
Auto Select No, Yes
Graphics Speed Low, High
Centering Position DEFAULT, MODE 1, MODE 2
* Appears only when the IBM emulation is selected.
