Oki B431L6

Appendix C Maintenance Manual for Second Tray unit
Oki Data CONFIDENTIAL
44983601TH Rev.1
Appendix C-10 /
3.3.5 Gear-Assy-Clatch(Hop,Regist),Motor-Pulse
(1) RemovetheCover-Rear,Cover-Blind-R/L,Plate-Top.(Referto3.3.3)
(2) Removethetwoscrews(Black)
,disengagethetwotabs,andremoveCover-Front .
(3) Removethefourscrews(Black)
.Removethetwoscrews(Silver) .
(4) DisconnecttheveconnectorsfromBoard-GOG,andremoveFrame-Assy-Hop
.
②
①
①
③
④
④
⑤
③
