Oki C301 Maintenance Manual

44951501TH Rev.2
7-31
Oki Data CONFIDENTIAL
7. TROUBLESHOOTING
Lock lever
(blue)
Lock lever
(blue)
(7) Turn the lock levers inwards to lock the belt unit.
(8) Put the fuser unit back into position.
(9) Turn the lock levers inwards to lock the fuser unit.
(10) Install the image drum unit in the printer so as to situate the K toner cartridge
toward the front of the printer.
(11) Close the top cover.
Handle (blue)
Handle (blue)
Fuser unit lock levers (blue)
Handle
Fuser unit lock lever
(blue)
Fuser unit lock lever
(blue)

Oki C301 Specifications

General

Print Speed (Color)	20 ppm
Monthly Duty Cycle	30, 000 pages
Memory	128 MB
Paper Capacity	250 sheets
Duplex Printing	Manual
Print Technology	LED
Connectivity	USB 2.0, Ethernet
Printer Type	Color
Media Size	A4, A5, A6, B5, Legal, Letter, Executive, Envelopes
Operating System Compatibility	Windows, Mac
