Oki C301 Maintenance Manual

44951501TH Rev.2
4-6
Oki Data CONFIDENTIAL
4.REPLACEMENT OF PARTS
4.2.4 Right side cover
(1) Open the top cover.
(2) Remove the cassette assembly.
(3) Remove the interface cover
.
(4) Loosen the screw
to remove the memory cover
(5) Open the MPT assembly
(6) Remove the two (black) screws and one (silver-colored) screw .
(7) Unlatch two portions A and B to detach the right side cover
.
4.2.5 Face-up tray
(1) Open the face-up tray
in the direction of the arrow and, warping it, disengage
two portions to detach the face-up tray.
MPT Assy
Latches A
Latch B

Oki C301 Specifications

General

Print Speed (Color)	20 ppm
Monthly Duty Cycle	30, 000 pages
Memory	128 MB
Paper Capacity	250 sheets
Duplex Printing	Manual
Print Technology	LED
Connectivity	USB 2.0, Ethernet
Printer Type	Color
Media Size	A4, A5, A6, B5, Legal, Letter, Executive, Envelopes
Operating System Compatibility	Windows, Mac
