44951501TH Rev.2
5-9
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
[
▲
]
LEVEL1
SWITCH
SCAN
PAPER ROUTE :
PU
TONER SENS
CVO UP_LU_FU
REG L/
R_OHP_WG
HT
THERMISTER
HUM_TEMP
_DEN
BELT_T
ID UP/DOWN
TAG COLOR
DISTONER
FULL_BOX
T1 PE_PNE_
CVO_CA
T1 HOP_LIFT
T2 PE_PNE_
CVO_CA
T2
HOP_LF_FED
DUP RA_FNT
Note:
Refer to a Switch Scan
test sheet.
[
▼
]
MOTOR &
CLUTCH
TEST
ID MOTOR
BELT MOTOR
FUSER MOTOR
REGIST MOTOR
T1 HOPPING
MOTOR
FRONT MOTOR
REGIST
SHUTTER
DUPLEX
MOTOR
DUPLEX
CLUTCH
T2 HOPPING
MOTOR
T2 FEED
CLUTCH
ID UP/DOWN
LV FAN TEST
ID FAN TEST
FRONT FAN
TEST
Note:
A motor is kept running by
holding down the OK button
(for two seconds) to determine
the motor.
TEST PRINT
PRINT
EXECUTE
TEST
PATTERN
TEST
CASSETTE
*1
PAGE
COLOR
DUPLEX
*1: TRAY2 is displayed
only when the printer
has the tray 2 in it.
REG ADJUST
TEST
REG ADJ
EXECUTE
REG ADJ RESULT
*2
BLT REFLECT TEST
BLT REFLECT
RESULT
[
▼
]
ENGINE DIAG LEVEL1
DENS ADJ
TEST
DENS ADJ
EXECUTE
DENS ADJ PAR-
SET
DENS ADJ
RESULT *3
AUTO
CALIBRATION
AUTO CALIB
BLACK
CONSUMABLE
STATUS
K-ID UNIT
Y-ID UNIT
M-ID UNIT
C-ID UNIT
FUSER UNIT
TR BELT UNIT
K-TONER (FULL)
Y-TONER (FULL)
M-TONER (FULL)
C-TONER (FULL)
K-STC MODE CNT
Y-STC MODE CNT
M-STC MODE CNT
C-STC MODE CNT
K OVER RIDE CNT
Y OVER RIDE CNT
M OVER RIDE CNT
C OVER RIDE CNT
Note:
A parameter reset is
performed by holding
down the OK button (for 10
seconds).
PRINTER STATUS
K-IMPRESSIONS
Y-IMPRESSIONS
M-IMPRESSIONS
C-IMPRESSIONS
TOTAL SHEETS CNT
FACTORY
MODE SET
FACTORY MODE
*5
FUSE INTACT
*6
SENSOR
SETTING
TONER
SENSOR
BELT UNIT
CHECK
ID UNIT
CHECK
UP/DOWN
SENSOR
REG ADJ
ERROR
DRUM OVER
LIFE
WR POINT
REV
BOTTOM
WRT POINT
Note:
A parameter determination is
made by holding down the OK
button (for three seconds).
LED HEAD
DATA
K
Y
M
C
[
▲
]
[
▼
]
[
▲
]
Color registration adjustment test result
display items below option marked with
*2:
REG ADJ RSLT
SNS CARIBRAT (L) FINE ADJ Y [Y-L]
SNS CARIBRAT (R) FINE ADJ Y [Y-L]
D-RANGE (L) Y,M,C FINE ADJ Y [Y-R]
D-RANGE (R) Y,M,C FINE ADJ Y [Y-R]
CRSE ADJ Y L,R,X FINE ADJ Y [X-L]
CRSE ADJ M L,R,X FINE ADJ Y [X-R]
CRSE ADJ C L,R,X FINE ADJ M [Y-L]
FINE ADJ Y L,R,X FINE ADJ M [Y-L]
FINE ADJ M L,R,X FINE ADJ M [Y-R]
FINE ADJ C L,R,X FINE ADJ M [Y-R]
REG ADJ Y L,R,X FINE ADJ M [X-L]
REG ADJ M L,R,X FINE ADJ M [X-R]
REG ADJ C L,R,X FINE ADJ C [Y-L]
CRSE ADJ Y [Y-L] FINE ADJ C [Y-L]
CRSE ADJ Y [Y-R] FINE ADJ C [Y-R]
CRSE ADJ Y [X] FINE ADJ C [Y-R]
CRSE ADJ M [Y-L] FINE ADJ C [X-L]
CRSE ADJ M [Y-R] FINE ADJ C [X-R]
CRSE ADJ M [X]
CRSE ADJ C [Y-L]
CRSE ADJ C [Y-R]
CRSE ADJ C [X]
Density adjustment test result
display items below option marked
with *3:
DENS ADJ RESULT
LEV0 V/D OUT YMC
LEV0 V/D OUT K
LEV0 V/D OUT RD
LEV0 V/D OUT YMC
LEV0 V/D OUT K
H_DUTY DENS-K
H_DUTY DENS-Y
H_DUTY DENS-M
H_DUTY DENS-C
L_DUTY DENS-K
L_DUTY DENS-Y
L_DUTY DENS-M
L_DUTY DENS-C
FINAL DENS-K
FINAL DENS-Y
FINAL DENS-M
FINAL DENS-C
DB DENS VALUE
DELTA-K 01=#***
DELTA-K 04=#***
DELTA-K 07=#***
DELTA-Y 01=#***
DELTA-Y 04=#***
DELTA-Y 07=#***
DELTA-M 01=#***
DELTA-M 04=#***
DELTA-M 07=#***
DELTA-C 01=#***
DELTA-C 04=#***
DELTA-C 07=#***
DENS-K
Options below FACTORY MODE SET option *5
FACTORY MODE
FACTORY MODE A factory working mode.
SHIPPING MODE Deselects a factory working mode.
Note: A parameter determination is made by holding
down the OK button (for three seconds).
Options below FUSE INTACT option *6
FUSE INTACT
BELT UNIT INTACT: Has not be blown./BLOWN:
Already blown.
FUSE UNIT INTACT: Has not be blown./BLOWN:
Already blown.
ID UNIT INTACT: Has not be blown./BLOWN:
Already blown.
LED head serial
number display
n 01 23 45 6789
1234567890123
n: K, Y, M, C
NVRAM
PARAMETER
CLEAR
[
▲
]
[
▼
]
[
▲
]
[
▼
]
[
▲
]
[
▼
]
[
▲
]
[
▼
]
[
▲
]
[
▼
]
[
▲
]
[
▼
]
[
▲
]
[
▼
]
[
▲
]
[
▼
]
DENS-Y
DENS-M
DENS-C
BEF COL STD=***H
AFT COL STD=***H
BEF BLK STD=***H
AFT BLK STD=***H
[
▲
]
[
▼
]
(1) Menu option switching
or is used to select the option shown in a shaded area ( XXXXX ), and pressing OK executes the option. OK or is used to switch to the option in a non-shaded area
(
XXXXX ), and, after that, or is used to select an option. A selected test is executed by pressing OK, and ended by pressing .
