19
•
C610
•
English
Clearing Media Jams (cont.)
6.
To remove a sheet just
entering the fuser, separate
the trailing edge of the
sheet from the belt, pull the
fuser pressure release lever
(1) towards the front and
remove the sheet. Then
release the lever.
7.
If the sheet is well advanced
into the fuser:
a. Push the two retaining
levers (1) towards the front
of the printer to release the
fuser. Withdraw the fuser
unit using the handle.
b. Press release lever (1) and
pull the trapped paper from
the fuser.
c. Replace the fuser unit and
push the lock levers toward
the rear of the printer.
To Next Page
