C610/C711 Memory Installation > 3
C610/C711 M
EMORY
UPGRADE
The basic printer model comes equipped with 256MB of main memory.
This can be upgraded with an additional memory board of 256MB or
512MB, giving a maximum total memory capacity of 768MB.
1. Switch the printer off and disconnect the AC power cable.
2. Press the cover release and open the printer’s top cover fully.
3. Pull down the MP Tray using the depressions. Lift the front cover
release lever and lower the front cover.
4. Loosen the screw (a) securing the right-hand side cover.
WARNING!
If the printer has been powered on recently, the
fuser will be hot. This area is clearly labelled.
Do not touch.
OI
