Oki C831dn - Page 120

- 120 -
Replacing Consumables and Maintenance Units
4
4. Maintenance
6 Cover the image drums you took out
with paper so that the image drums do
not expose to the light.
7 Turn the blue locks (5) on each side of
the belt unit in direction of the arrow to
unlock.
5
5
8 Remove the belt unit by holding the blue
lever (6).
6
9 Hold the handle of a new belt unit with
one hand and support lower part with
other hand. Place the belt unit into the
printer.
➌
➊
➋
➍
10 Turn the blue locks (5) on each side of
the belt unit in direction of the arrow.
5
5
