Oki C8800dn Network User's Guide

Microsoft Windows > 44
N ETWORK PRINTER IP ADDRESS CONFIGURATION
Use the Standard Set-up Utility to configure the IP Address,
Subnet Mask and Gateway.
1. Connect the printer to the network and turn on.
2. Insert the CD-ROM into the CD-ROM drive. The Setup
Utility starts automatically. If it does not start, double-
click \setup.exe (in the root directory) on the CD-ROM.
3. Select the
appropriate
language and follow
the on-screen
instructions.
4. Accept the Software
License Agreement.
5. Select the Optional
Utilities tab.
6. Then select Install Admin Manager.
NOTES:
It will not be necessary for printers connected to a network
using DCHP to use this setup method.
Some steps may not display depending on the network
protocols installed.

Oki C8800dn Specifications

Performance

print speed color	26 ppm
print speed monochrome	32 ppm
time to first page color	10 sec.
time to first page monochrome	9 sec.
processor	500 MHz PowerPC CPU
print resolution	1200 x 600 dpi
duty cycle	75, 000 pg./mo.

Memory

standard memory	256 MB
maximum memory	768 MB
memory storage option	40 GB Hard Disk Drive

Paper Handling

paper input standard	400 sheets
paper input maximum	930 sheets
multi-purpose tray capacity	100 sheets
paper sizes main tray	4.1" x 5.8" to 11" x 17"
paper sizes 2nd tray	5.8" x 8.3 to 8.5" x 14"
paper sizes multi-purpose tray	3" x 5" to 11.6" x 47.24" banner

Supplies

toner cartridge life	6, 000 pages each (CMYK)
image drum life	20, 000 pages

Weight and Dimensions

size without duplex	19.1" x 23.3" x 13.4"
size with duplex	19.1" x 25.5" x 13.4"
size with duplex and 2nd tray	19.1" x 25.5" x 19.3"
weight without duplex	76.5 lb. (34.7 kg)
weight with duplex	85.6 lb. (38.8 kg)
weight with duplex and 2nd tray	100.9 lb. (45.7 kg)
