Oki C8800dn Network User's Guide

Microsoft Windows > 47
N ET BEUI P ROTOCOL
N ETWORK P RINTER S ETTINGS
There are two configurable items under NetBEUI within the
printer. These can be configured using the standard set-up utility
described in “Device setup” on page 13.
Although there are some differences in configuration options
between the various Windows platforms, the procedure for
printing using NetBEUI is the same.
Please ensure the NetBEUI protocol has been installed in
Windows. This can be confirmed by checking the network
settings. If NetBEUI has not been installed please refer to the
section below.
The relevant Windows installation CD-ROM may be required and
you should follow the on-screen dialogue box prompts.
W INDOWS XP
Although you can install the NetBEUI protocol into Windows XP,
it may not be supported. You should be able to use NetBEUI on
LAN connections although you will not be able to use this on a
Remote Access Service Connections.
1. In the Start menu, select Settings then Control Panel.
2. Double-click on Network Connections.
3. Right-click the adapter you wish to add NetBEUI to and
then click Properties.
4. On the General tab, select Install.
5. Select Protocol and then Add.
COMPUTER NAME NAME ASSIGNED TO THE PRINTER
Workgroup
PrintServer
1
1. Although the workgroup name can be changed, it is recommended
that it remains as PrintServer.
Comment User definable description

Oki C8800dn Specifications

Performance

print speed color	26 ppm
print speed monochrome	32 ppm
time to first page color	10 sec.
time to first page monochrome	9 sec.
processor	500 MHz PowerPC CPU
print resolution	1200 x 600 dpi
duty cycle	75, 000 pg./mo.

Memory

standard memory	256 MB
maximum memory	768 MB
memory storage option	40 GB Hard Disk Drive

Paper Handling

paper input standard	400 sheets
paper input maximum	930 sheets
multi-purpose tray capacity	100 sheets
paper sizes main tray	4.1" x 5.8" to 11" x 17"
paper sizes 2nd tray	5.8" x 8.3 to 8.5" x 14"
paper sizes multi-purpose tray	3" x 5" to 11.6" x 47.24" banner

Supplies

toner cartridge life	6, 000 pages each (CMYK)
image drum life	20, 000 pages

Weight and Dimensions

size without duplex	19.1" x 23.3" x 13.4"
size with duplex	19.1" x 25.5" x 13.4"
size with duplex and 2nd tray	19.1" x 25.5" x 19.3"
weight without duplex	76.5 lb. (34.7 kg)
weight with duplex	85.6 lb. (38.8 kg)
weight with duplex and 2nd tray	100.9 lb. (45.7 kg)
