17. Insert the orange cable (4 leads) into the
connector on the hole punch unit board.
18. Insert the purple cable (5 leads) into the
connector on the hole punch unit board.
19. Snap open the four cable harnesses, then
thread the two cables through the harnesses
and snap each one shut.
20. Plug the orange cable into the connector on
the main board.
21. Plug the purple cable into the connector on
the main board.
