- 159 -
Matching Colors Using Utilities
4
3
5
1
2
Convenient print
functions
Appendix Index
Checking and
Changing Printer
Settings Using
the Control Panel
Network
Setup
Matching
Colors
Using Utility
Software
Memo
z
The overall brightness can be adjusted using the
gamma slide bar, and the output colors adjusted
using the hue/brightness slide bars.
z
The further to the left the [Gamma] is adjusted,
the brighter the image.
z
The matched colors can be switched using the
printer color buttons.
z
Adjust the [Hue] for each color either clockwise
(+) or counterclockwise (-) in the color circle.
For example, moving the Y (yellow) slide bar
clockwise (+) the color approaches G (green),
and moving the bar counterclockwise (-) the
color approaches R (red).
C(Cyan) R(Red)
Y(Yellow)G(Green)
B(Blue) M(Magenta)
(-)
z
[Use printer's unadjusted color.] adjusts so that
the 100% of the primary toner colors are used.
Enable this check box to anchor the [Hue] slider
bar for the relevant color, and adjust so that
printing arranges the toners as described below.
Printer
Colors
Result
Cyan (C) Cyan toner 100%
Magenta (M) Magenta toner 100%
Yellow (Y) Yellow toner 100%
Red (R) Magenta toner 100% + Yellow toner 100%
Green (G) Cyan toner 100% + Yellow toner 100%
Blue (B) Cyan toner 100% + Magenta toner 100%
(6)
Click [Print Palette].
"TEST PRINTING SAMPLE" will be printed.
(7)
Check the adjusted results.
If the desired match results have not
been obtained, repeat Steps (5) and (6).
(8)
Click [Next].
(9)
Enter a name for your Color
Settings and click [Save].
(10)
Click [OK].
Note
z
If updating or reinstalling the printer drivers, when
the Color Correct Utility is started, the matched
color names that have been created will be read
again. Check that the matched color name is
displayed in [Setup Selection], and click [Finish].
(11)
Click [Finish] to îš¿nish the Color
Correct Utility.
To Next Page
