Oki MB770 Maintenance Manual

45372301TH Rev.2
1-3 /
Oki Data CONFIDENTIAL
1.2 Accessory
Fig. 1-3
Symbol Name
Quan-
tity
Symbol Name
Quan-
tity
A Stacker tray 1pc a Screw: M4x6 2pc
B BKT MOUNT LEFT 1pc b Screw: M3x6 6pc
C BKT MOUNT RIGHT 1pc c Screw: M3x10 2pc
D Paper Guide 1pc d Screw: M3x8 1pc
E Film 2 sheets e Screw: M3x12 3pc
F Film 1 sheet
G Control Panel Fixing Plate 1pc
H Stopper (A) 1pc
I Stopper (B) 1pc
J Damper 1pc
Unpacking Instruction 1set
M4x6 M3x6
6pcs
M3x10
M3x8 M3x12
3pcs
A
E
C
D
F G H I
J
a
b
c ed
B
