Getting Started E-11
4. Adjust the paper feed guides (
Ë
) for the width of the
paper and drop a sheet of paper into the separator.
The paper will automatically feed into the printer, and
the printhead will move back and forth, gently firing
the pins to sense the paper thickness and set the
printhead gap.
4
If the paper doesn’t feed in properly, the “15” light
on the control panel will begin flashing. To correct
this, press the SHIFT and RESET buttons simulta-
neously, then reload the sheet.
5. Check the baseline for the Top of Form (TOF), indi-
cated by the red line on the clear plastic paper shield
(
Í
).
If it’s OK, press the SEL button and you’re ready to
start printing. If it needs adjustment, set the Top of
Form following the instructions on the next page.
Ë
Í
To Next Page
