1 – 7
Loading Rear Feed Continuous-Form Paper
When printing on rear feed continuous form paper use the built-in tractor.
1. Lift the rear paper guide
into the upright position.
2. Move the centre paper supports, on the tractor unit, to the middle of the paper.
3. Move the left hand tractor to the required position. (Pull the lever forwards to
unlock the tractor and slide to adjust. Push the lever back to lock.)
Paper support
Paper guide removed
for clarity
Tractor unit
Paper lever
To Next Page
