E-2 Section 1
2. Lift up on the ridged area at either end of the carriage
cover.
3. Peel the clear protective film from the access cover.
4. Press the carriage cover back into place.
Remove The Shipping Retainers
1. Open the access cover (
Ê
) by grasping the tabs at
either end and lifting, then remove the printhead
shipping retainer (
Ë
), leaving the cover open for
installation of the ribbon.
2. Grasp the front edge of the paper separator (
Ì
) and
pull it up.
Ì
Ê
Ë
To Next Page
