Ethernet Interface
PIN SIGNAL I/O
1 Data Out + Output Data +
2 Data Out - Output Data -
3 GND Ground
4 Data IN + Input Data +
5 Data IN - Input Data -
6 N.C
7 N.C
8 N.C
9Pin Serial
Pin Signal I/O Description
2 RXD Input Printer receive data line RS-232C level
3 TXD Output Printer transmit data line RS-232C level
4, 7 DTR Output Printer handshake to host line RS-232C level
5 GND - System Ground
6 DSR Input Data Send Ready
1,8,9 NC -
RJ45 Modular Serial Card
Pin Signal I/O Description
1 N.C - -
2,6 DSR Input Data Send Ready
3 TXD Output Printer transmit data line RS-232C level
4 RXD Input Printer receive data line RS-232C level
5,8 DTR Output Printer handshake to host line RS-232C level
7 GND - System Ground
Wireless LAN Card
The WiFi USB Dongle is suggested to use suitable KC Certification Production.
Please do not connect both of 9Pin Serial Cable and RJ45 Modular Serial Cable at the same time.
