Corner Panels
Mid-Wall Brace
Top-Wall Brace
1
Fix top rail 'H' and mid-wall rail
'HA' to front corner 'F'(or 'F6')
to
stabilise front corner before
fitting back corners.
F or F6
H
H = Top Rail
Curved side of H rail
for roof fixing, flat side
for wall fixing
HA
HA = Midwall Rail
H
HA
B
A
B
X20
X20
Note: brace mid-
wall rail 'HA' and
top
rail 'H' against
ground surface
to stabilise front
corner panel.
HA
2
Fix back corner panel 'F' to back side of shed with
short side of corner panel 'F' to side base rail 'B' and
use 4
x 'X12' to fix to base rail 'B' and 'A'. Follow
'X12' fixing order diagrams.
H
1
4
3
2
X12
X12
A
B
B
F
STEP 3 - Continued
13
F or F6
To Next Page
