Oldfield Treco 63 - Step 3: Wall Panel Installation

Note: All corner panels must be screwed
to base rails according to the order and
position in the diagrams shown.
1
2 3 4
F
1
2
F6
Corners 'F' and half corners 'F6' supplied with 45° degree bend. With a supporter,
bend the panels 90° degrees manually. (Do not over bend).
F
F
Supporter
Use 'F6' (front half corner panel)
for 6' shed models only.
F6
F6
Supporter
INSTALLING CORNER PANELS, MID & TOP WALL BRACES AND WALL PANELS
Corner Panels
A
B
F
or F6
B
1. Fix corner panel
with short side of
corner panel to
side base rail 'B'.
X20
X20
1
4
3
2
Use 'F' for all 8' and 10' shed models.
STEP 3
12
