Oldfield Treco 63 - Step 6: Roof Panel and Capping Installation; Roof End Panels, Roof Panels, and Capping

INSTALLING ROOF END PANELS, ROOF PANELS, ROOF CAPPING AND TRIMS
Roof End Caps
All fasteners on roof need washers 'X11' attached.
Fix roof ends 'RQ' with bolts & washers from top of appex
to
the side wall, as shown in diagram.
Fix screws & washers to roof beam(s) 'P' and side rails 'H'.
X13A
X11
X13B
Panel to
Panel
3/16"
Nut
& Bolt
X12
X11
Panel to
Frame
P
RQ
RQ
RQ
RQ
P
P
X12
P
X12
X11
X13B
X13A
X13B
X13A
X12
H
H
Note: Please seal
all un-used pre-
punched holes in
the roof using 3/16"
bolts and nuts
'X13A + X13B'
and plastic washers
'X11' supplied.
STEP 6
19
