DYNA-BOLTING BASE RAILS TO CONCRETE AND SEALING FLOOR
6.5mm x 36mm Dynabolt
Roof Trims
Seal with silicone on inside of base
frame after bolting down shed.
X10
X13B
U2
U3
X13A X11X11
X13A
X11
T
X8
X13B
Place silicone inside shed between
base rail and floor
STEP 7
STEP 6 - Continued
Fix roof end cap to front and back on top roof capping.
Fix roof edge trim 'T' to side of roof with corner caps 'X8'
to each corner.
'X10'
21
