TECHNICAL SPECIFICATIONS
MODEL1. OM
GS 35 C GS 350 C
ENGINE
TYPE Emak 2-stroke (EURO I) Emak 2-stroke (EURO 2) with catalyst
DISPLACEMENT cm
3
38.9
BORE x STROKE mm x mm 40 X 31
MAXIMUM POWER OUTPUT HP/kW (rpm) 2.0 / 1.48 (9000)
MAXIMUM TORQUE Nm (rpm) 2.15 (6500)
IDLING SPEED rpm 3000
MAXIMUM NO LOAD SPEED with limiter rpm 13000
HOURLY FUEL CONSUMPTION (at max power output) g/h (rpm) 750
EMISSIONS (HC+Nox) gr/kWh 150 48
CRANKCASE Aluminium
IGNITION SYSTEM
TYPE Capacitive electronic
COIL Analogic
FLYWHEEL mm 100
SPARK PLUG
CHAMPION RCJ-7Y
ICE DEVICE SYSTEM Yes
FUEL & LUBRICATION SYSTEM
CARBURETTOR Ruixing
CARBURETTOR BRACHET With 4 anti-vibration mounts
AIR FILTER Sponge + cloth
FUEL Mix 4% with PROSINT oil 2% (50:1)
FUEL TANK CAPACITY l 0.35
PRIMER Yes
TRANSMISSION SYSTEM
TRANSMISSION Chain sprocket outside clutch bell (reversed)
CLUTCH 2 parts
N° SPROCKET TEETH 6
CHAIN SPEED m/s 17.2 (9000)
TYPE TEST APPROVALS
SOUND PRESSURE (LpA av EN 11681-1 EN 22868) dB(A) 99.6
SOUND POWER (LwA 2000/14/EC, EN 22868, EN ISO 3744) dB(A) 113
VIBRATION LEVEL (EN 11681-1,EN 22867,EN12096) m/s
2
6.0 (SX) - 6.7 (DX) con barra da 14-16”
UNCERTAINTY (EN 12096) m/s
2
1.5 – 2.0
ERGONOMICS
ANTI-VIBRATION SYSTEM On 4 anti-vibration mounts
BAR AND CHAIN CUTTING SYSTEM
BAR LENGTH inch (mm) 14-16 (350 - 410)
CHAIN PITCH inch (mm) 3/8 x .050 (1.3)
CHAIN BRAKE Inertia-activated
CHAIN GUARD Plastic
CHAIN TENSIONER Front
OIL RESERVOIR CAPACITY l 0.26
OIL PUMP Plastic + metal
OIL PUMP Automatic
BUCKING SPIKE Plastic
WEIGHT (without bar/chain)
kg 4.4
POWER-TO-WEIGHT RATIO
kg/kW 3.1
