Page 14
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
j. Optional Mounting Kit
Wall or 2” Pipe Mounting Kit, includes bracket and hardware
(Part # SX1000-MK10)
Dimensions:
4.1” (W) x 4.6” (H) x 3.9” (D) / 10.4 cm(W) x 11.6 cm (H) x 9.8 cm (D)
Provided DP Transmitter mounting bolt size: M10
Provided wall mounting bolt size: M8
Provided U-Bolt: Heavy duty exhaust clamp with 2.5” U-Bolt
