Page 34
DIFFERENTIAL PRESSURE TRANSMITTER - USER GUIDE
2. Basic LCD Functions – 1-5 V
a. Set the Pressure Value (PV) = 0 Atmospheric Pressure
b. PV (Pressure Value) and SV (Secondary Value) Auto Switching
display
The PV and SV display on two rows. The PV, pressure value is
displayed continuously on the top row in large font. The PV
engineering units and the temperature values alternate displaying
every four seconds each on the bottom row.
Default temperature unit is °F.
c. Backlight Settings (1-5 V Models Only)
d. Factory Reset
