OLI eBike Systems | High Vision
INSTALLATION
GENERAL
INFORMATION
KEYPAD INSTALLATION
1 > Position the keypad while paying attention to the
angle (15 ° - 35 ° with respect to the horizontal plane),
so as to allow the user to operate it comfortably while
moving.
2 > Tighten the fixing screws.
1.5 - 3 Nm
3
3 > Insert the display cable into the frame to be able
to connect it to the power unit.
studioimmagina.com 00_102020
10
