OLI eBike Systems | High Vision
INSTALLATION
GENERAL
INFORMATION
DISPLAY INSTALLATION
1 > Insert the display holder rings on the handlebar.
2 > Install the display on the support, tightening the
M4 fixing screws.
1.5 - 3 Nm
INSTALLATION
