2.6.1
Cleaning the air filter
Removing or cleaning the filter must be performed with the unit deenergized.
The procedure for removing the filter is as follows:
Manually unhook and turn the front air aspiration grill as indicated in fig. 25
Lift the front part of the filter (fig. 25 ref. A)
Pull slightly to remove the edge from the upper grid (fig. 25 ref. B)
Remove the two supplementary filters (green purifying filter ref. B and black active carbon filter ref. C) from the filter unit (fig.27 ref. A).
Carefully wash and dry the filters
Fit the black active carbon filter (fig. 26 ref. C) on the filter rack (fig. 26 ref. A) and lock it to the specific tongues (fig. 26 ref. D)
Fit the purifying filter (green) (fig. 26 ref. B) on the first pin that is on the filter unit (fig. 26 ref. E), pull it slightly and lock it on the other two
pins (fig. 26 ref. F)
Refit the filter unit by inserting the rear edge (fig. 27 ref. B) into the grid (fig. 27 ref. A)
Lower the front edge (fig. 27 ref. C) on the unit
Reclose and hook the front air aspiration grill
To deactivate LED A (if on), after having powered and started the appliance, press the micro key positioned on the signal console(fig. 22 ref.
H) with a pointy object for a brief instant. By doing so, the signal related to the filter cleaning requirement is reset.
