0723S20004
If it seems necessary to adjust this guide loosen the two knobs which are on the top and
to the inside of the table, then slide the guide in or out to conform with product width.
Make a liberal adjustment to allow for product variances. Re-tighten the knobs to secure
it in the desired position.
SLOW-DOWN DOOR ADJUSTMENT
On the discharge end of the chute you will find a small adjustable door used to slow the
product as it exits the blade. Generally heavier products require a lower door setting
while lighter products require less restriction. The door is raised by turning the knob in a
clockwise direction. Turning the knob in the opposite direction will lower the door.
Normally if a bun should stop beneath the door the next bun should dislodge it, if it does
not then the door should be adjusted to provide less restriction.
WARNING
NEVER STICK YOUR HAND OR ANY OTHER OBJECT INTO EITHER
END OF THE CHUTE. ALWAYS KEEP YOUR HANDS AWAY FROM
THE MOVING PARTS OF THE MACHINE.
