777-NT Variety Slicer
0777S20033 rev. 1/7/15 0-1
INDEX
Section Description Document No. Page No.
SAFETY INSTRUCTIONS ----------------------------------- 0777S20034 -------------- 1-1
DESCRIPTION/SPECIFICATIONS -------------------- -- 0777S20035 ---------------- 2-1
Description -------------------------------------------------------------------------------------- 2-1
Specifications----------------------------------------------------------------------------------- 2-1
INSTALLATION INSTRUCTIONS --------------------- 0777S20036 ---------------- 3-1
Removing the Slicer from the Shipping Platform ------------------------------------- 3-1
Installing the Rubber Feet ------------------------------------------------------------------ 3-2
Installing Optional Casters ----------------------------------------------------------------- 3-2
OPERATING INSTRUCTIONS ---------------------------- 0777S20037 ---------------- 4-1
TROUBLESHOOTING --------------------------------------- 0777S20038 ------------------5-1
The Slicer Will Not Start (Motor is Not Humming) ------------------------------------ 5-1
The Slicer Will Not Start (Motor is Humming) ------------------------------------------ 5-2
The Slicer Starts Without Pulling the Knob --------------------------------------------- 5-2
The Slicer Does Not Stop When Slicing is Complete -------------------------------- 5-2
The Slicer Stops Before Slicing Starts or is Complete ------------------------------- 5-2
Bread Slices Vary in Thickness ----------------------------------------------------------- 5-2
The Blade Frames are Knocking ---------------------------------------------------------- 5-3
MAINTENANCE --------------------------------------------- 0777S20039 ------------------- 6-1
Cleaning ----------------------------------------------------------------------------------------- 6-1
Lubrication -------------------------------------------------------------------------------------- 6-1
Removing the Blade Frames --------------------------------------------------------------- 6-1
Replacing the Blade Frames --------------------------------------------------------------- 6-4
Changing the Blades ------------------------------------------------------------------------- 6-5
Tightening the Belt ---------------------------------------------------------------------------- 6-7
Replacing the Belt ---------------------------------------------------------------------------- 6-8
Adjusting the Blade Frames When Slices Vary in Thickness ---------------------- 6-9
Adjusting the Clearance Between the Blade Frames -------------------------------- 6-9
RECOMMENDED SPARE PARTS -------------------- 0777S20040 -------------- 7-1
REPLACEMENT PARTS SECTION
ASSEMBLY DRAWING (FRAME & BASE) --------- 0777S20041 ---------------- 8-1
REPLACEMENT PARTS (FRAME AND BASE) ----- 0777S20041 ---------------- 8-2
