EXPLOR@460

Chapter 5

2.3. VGA Port

VGA DE-15

PIN Description PIN Description

1 RED 9 KEY/PWR

2 GREEN 10 GND

3 BLUE 11 ID0/RES

ID2/RES

ID1/SDA

GND

HSync

6 RED_RTN 14 VSync

GREEN_RTN

ID3/SCL

BLUE_RTN
