EXPLOR@460

Chapter 5

2.4. COM 1.2 (10-Pin RJ50)

PIN Signal Name PIN Signal Name

1 XRIA_N 6 XRXDA

2 XDSRA_N 7 GND

3 XRTSA_N 8 XCTSA_N

4 GND 9 XDTRA_N

5 XTXDA 10 XDCDA_N
