EXPLOR@460
Chapter 1
12
2nd Display
1. Make sure that all items (shipped with your 2nd display) listed below are ready.
1.
2nd display support
4.
base bracket
2.
Plastic bush
5.
M3 screw X 4
3.
Plastic spacer
6.
M4 screw X 2
2. Remove the 2nd display mounting hold cover from the base.
3. Insert the plastic bush into the base as shown.
