Upgrading The Computer
Upgrading the HDD 6 - 5
6
4. Carefully lift the hard disk assembly up out of the bay.
5. Remove screws - from the hard disk assembly.
6. Separate the hard disk from the case.
7. Insert the new hard disk into the case and pay careful attention to the disk’s
orientation in the case.
5
3

Hard Disk Drive
Speeds
If you are going to up-
grade/replace the hard
disk drive, note that It is
recommended that
HDDs of a maximum
speed of 5400 RPM are
used. DO NOT use
7200rpm or higher
HDDs.
3
2
1
5
4
5
7
Figure 6 - 4
HDD Removal
