Additional Modules
Wireless LAN Module 7 - 5
7
802.11b/g or 802.11n WLAN Driver Installation
1. Make sure the module is powered on, and then insert the Device
Drivers & User’s Manual disc into the CD/DVD drive.
2. Browse the CD and go to the Drivers / WLAN folder .
3. Start the executable file ( “Setup.exe” ) .
4. Choose the language you prefer and click Next.
5. Click Next > Install.
6. Click Finish.
7. The operating system is the default setting for Wireless LAN control in
Windows XP.
Network
Connection
Use the Windows Net-
work Connections con-
trol panel to access
available wireless net-
works (Start > Settings >
Network Connections or
Start > Connect To >
Show all Connections).
Figure 7 - 1
Wireless Network
Control Panels
To Next Page
