COOLING OR HEAT PUMP HEATING
SW2 COOL
DIP SWITCH POSITION
AC SIZE
[TONS]
CFM WITH SW3-ADJ
DIP SWITCH POSITION A
CFM WITH SW3-ADJ
DIP SWITCH POSITION B
CFM WITH SW3-ADJ
DIP SWITCH POSITION C
A (1=OFF, 2=OFF) 3.5 1400 1600 1190
B (1=ON, 2=OFF)
3.0 1200 1380 1020
C (1=OFF, 2=ON)
2.5 1000 1150 850
D (1=ON, 2=ON)
2.0 800 920 680
The CFM's shown are reduced by 20% if 24 VAC input is to Y1 (slow speed of 2 speed compressor) instead of Y/Y2
APPENDIX A - CHECK OUT AND ADJUSTMENTS
Table A-11 Direct Drive Blower Characteristics - 1/2 HP ECM Variable Speed Constant CFM Motor - continued
DELAY PROFILE FOR OIL HEATING
SW4 DELAY
DIP SWITCH POSITION
INPUT
[USGPH]
PRE RUN ON DELAY
TIME - CFM LEVEL
SHORT RUN ON DELAY
TIME - CFM LEVEL
OFF DELAY
TIME - CFM LEVEL
A (1=OFF, 2=OFF) 0.65 60 SECONDS - 0% 60 SECONDS - 63% 2 MINUTES - 75%
B (1=ON, 2=OFF)
0.85 30 SECONDS - 0% 60 SECONDS - 63% 2 MINUTES - 88%
C (1=OFF, 2=ON)
0.75 60 SECONDS - 0% 60 SECONDS - 88% 2 MINUTES - 82%
D (1=ON, 2=ON)
0.55 60 SECONDS - 0% 60 SECONDS - 50 % 2 MINUTES - 69%
DELAY PROFILE FOR COOLING OR HEAT PUMP HEATING
NO ADJUSTMENT
REQUIRED
AC SIZE
[TONS]
PRE RUN ON DELAY
TIME - CFM LEVEL
SHORT RUN ON DELAY
TIME - CFM LEVEL
OFF DELAY
TIME - CFM LEVEL
N/A
ALL 7.5 MINUTES - 82% NONE NONE
