Parts Listing: Chimney Vent Models LRF/LRFV
Ref. No. Description Part No.
1 Left Side Panel 109009625AD
2 Right Side Panel 109009624AD
3 Base Panel Assembly 550003225
4 Rear Panel 109009626AD
5 Blower Door 109009809AD
6 Front Panel 109009786AD
7
Logo Bezel 28479
Logo Label Olsen 28563
Logo Label Airco 28564
8 Handle (2 per unit) 28673
9 Top Panel 109008787AD
10 Blower Division Panel 3002357
11 Inner Front Panel 109009627
12 Cleanout Cover (Includes one item 19) 550003223
13
Left Side Bafe
109009710
14 Right Side Bafe 109009709
15 Vertical Bafe (2 per unit) 109009711
16 Insulation Retainer (4 per unit) 26047
17 Heat Exchanger (Includes 18,19,20, 25) 550003224
18 Turbulators (18 per unit) 109009176
19 Cleanout Cover Gasket (2 per unit) 240010371
20 Burner Plate Gasket 240010370
21 Front Flue Pipe Assembly 3002314
22 Rear Flue Pipe Assembly 3002317
23 Flue Pipe Insulator Pipe 29713
24 Flue Pipe Flange 109009797
25 Flue Pipe Gasket (3 per unit) 240011382
26 Observation Port Sight Glass 240008235
27 Sight Glass Washer 109009449
28 Plug for Draft Measurement Port M10 x 16 Flange Bolt 240010827
29 Limit Disc 60T11 BOF 260°F 30153
30 Limit Disc Retainer 109009401
31 Control Box 30010
32
Control Box Cover (Direct Drive PSC Models) 109009791
Control Box Cover (Direct Drive ECM and Belt Drive Models) 29654
33
Fan Timer Control 1158-120 UTEC (PSC and Belt Drive Models) 29388
Fan Timer Control 1168-1 UTEC (ECM Models) 240007048
34 Transformer 120-24 VAC 40VA 240005330
35 Low Speed Fan Switch (Direct Drive PSC Models Only) 20693
36
Blower Assembly - Direct Drive PSC Motor (includes 39) 550003217
Blower Housing and Wheel 100-10T Direct Drive 240010315
Blower Motor 1/2 HP 4 Speed 102000131
Motor Mounting Band TR6884B 17811
Motor Mounting Arms 26251
Motor Run Capacitor 10 mfd @ 370 VAC 27743
Capacitor Strap 27761
Blower Base (2 per unit) 109005826
Grommet, Blower Feet (4 per unit) 26415
